500W DC Outdoor Telecom Cabinet Air Conditioner R134a Refrigerant CE Certified
Product Details
R134a Outdoor Telecom Cabinet Air Conditioner
,500W Outdoor Telecom Cabinet Air Conditioner
,CE Certified Telecom Cabinet Air Conditioner
Product Description
DC Series Air Conditioner
The DC Air Conditioner series is specially designed for DC powered application, by maintaining certain temperature to ensure lifespan of device. DC series is well functioned, high reliable, and easily installation. It can work promptly after power connection, no need for complicated debugging.
DC05HDNC1D is a pure DC powered air conditioner, with worldwide application history
Integrated design
Door mounted, well match with cabinet
Cooling capacity 520W(L35/L35)
Working temperature range: -40℃ to +55℃ with heater
Series product, cooling range: 300W ~ 5000W
Product Features
Environmental friendly – R134a and RoHS compliant
Energy saving
Protection for high voltage
LCD menu display, easily get data and alarm information
Design lifetime >10 years
Easy installation and minimum maintenance
IP55 protection level
Optional heater
Applications
Outdoor Battery Cabinets
Outdoor Radio Base Stations / Telecom Cabinets
Outdoor Power Supply Cabinets
Outdoor Gen-set Control Cabinets
Outdoor Solar Powered Telecom Cabinets
Outdoor Wind Power Control Cabinets
|
Dimensions, Weight & Mount
|
|
|
External Dimensions (H x W x D)
|
545×315×170mm
|
|
External Dimensions (H x W x D) With Flange
|
583×352×170mm
|
|
Weight
|
15 kg
|
|
Mounting Method
|
Door Mounted
|
|
Application
|
Outdoor
|
|
Environmental Protection & Performance
|
|
|
Working Temperature Range
|
-40 to +55ºC
|
|
Noise Level
|
60 dB(A)
|
|
IP Protection Level
|
IP 55
|
|
Refrigerant
|
R134a
|
|
RoHS2 Compliant
|
Yes
|
|
Cooling/Heating Capacity
|
|
|
Cooling Capacity@L25/L35
|
355W
|
|
Cooling Capacity@L35/L35
|
520W
|
|
Heating Capacity (Optional)
|
500W
|
|
Power Consumption
|
|
|
Power Consumption@L25/L35
|
150W
|
|
Power Consumption@L35/L35
|
160W
|
|
Current@L25/L35
|
3.20A
|
|
Current@L35/L35
|
3.34A
|
|
Airflow
|
|
|
Internal Airflow
|
150m3/h
|
|
Power Supply
|
|
|
Power Supply Range
|
-44~-58VDC
|
|
Rated operating voltage - Controller
|
-48VDC
|
|
Rated operating voltage - Cooling/Heating System
|
-48VDC
|
|
Max. Current
|
6.5A
|
Cooling Capacity Curve
Cooling Capacity Curve
Dimension Diagram
-
