Product Details:
Payment & Shipping Terms:
|
| Grounding Protection: | Copper Bar | Coating: | Anti-corrosion Outdoor Powder Coating |
|---|---|---|---|
| Cabinet Layout: | One Compartment | External Dimension: | H×W×D 2100×900×900 |
| Application: | Outdoor Telecom Base Station | Structure: | Double Wall, With Insulation, Sandwich Structure. |
| High Light: | power supply cabinet,outdoor power enclosure |
||
Outdoor Power Cabinet, Outdoor Telecom Cabinet With Water Sensor / Door Sensor
1. Description
The cabinet is one compartment cabinet. The cabinet cooling use air conditioner and heat exchanger, to ensure the equipments operate normally at stable temperature range, so as to make the service life of the equipments much longer and their performance more stable.
2. Applications
The DDTE069 Outdoor Telecom Equipment Cabinet is mainly used in wireless communication base station, such as 4G system, communication/network integrated service, access/transmission switching station, emergency communication/transmission, etc.
3. Quick Details
|
Place of Origin: Shenzhen, China (Mainland) |
External Dimension: H×W×D 2100×900×900 |
| Brand Name: ESTEL |
Structure: double wall, with insulation, sandwich structure |
| Model: DDTE069 |
Cabinet Layout: one compartment, the upper for installing equipment, the lower for installing batteries |
| Product Name:Outdoor Power Cabinet |
Cabinet Lock: anti-theft three point lock |
| Certification: ISO9001, CE, 3C, FCC, TLC, IP55 |
Protection Level: IP55 |
| Application: outdoor telecom base station |
Cable Entry: at cabinet bottom |
| Material: galvanized steel |
Illumination: DC48V LED lamp |
| Heat Insulation: PEF | Grounding Protection: copper bar |
| Color: grey (support custom made) | Cooling Method: DC48V heat exchangerr and DC48V peltier air conditioner |
| Coating: anti-corrosion outdoor powder coating | Accessories Options: PDU, rectifier system, environment monitoring system |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | L/C,D/A,T/T, Western Union, Paypal, etc |
| Supply Ability: | 6,000 sets per month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | wooden case |
4. Specifications
(1) Technical Parameters
| Item | Type | Technical Parameter |
| Structure | Dimension | External Dimension: H×W×D 2100×900×900 |
| Layout | 1 compartment | |
| Equipment Installation Method | 19” rack | |
| Door | With one front door, and anti-theft three point lock for outdoor cabinet (support padlock) | |
| Material | Galvanized steel; 1.5mm thick outer plate, 0.8mm thick inner plate | |
| Heat Insulation | There are heat insulation between inner wall and outer wall. The insulation material is 20mm PEF. | |
| Structure | Assembled | |
| Ingress Protection | IP55 | |
| Temperature Control | Cooling | DC48V Heat exchangerr and DC48V TEC air conditioner |
| Lightning Proof | Grade B lightning proof | Nominal: 60KA, Max.: 100KA |
| Lighting | LED lamp | 48V LED lamps (immovable), with protective circuit breaker |
| Temperature | Temperature | Working Temperature: -40°C ~ +55°C |
| Storage Temperature: -50°C ~ + 70°C | ||
| Transport Temperature: -50°C ~ +70°C | ||
| Humidity | Relative Humidity | 5% ~ 100% |
| Pressure | Air Pressure | 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude) |
| Radiation Intensity | Solar Radiation Intensity | 1120 ×(1±5%)W/m2 |
(2) Accessories List
| No. | Item | Quantity | Unit | Specs |
| 1 | Outdoor Telecom Cabinet | 1 | Set |
(1) External Dimension: H×W×D 2100×900×900 |
| 2 | Heat Exchanger | 1 | Set |
Cooling capacity: 150W/K, Power Supply:DC48V; |
| 3 | TEC Air Conditioner | 1 | Set |
Cooling capacity: 200W, Power Supply:DC48V; |
| 4 | Environment Monitoring Unit | 1 | Set | 19”, 1U; Model: SM2400. |
| 5 | Door Sensor | 2 | PC | One for controlling LED lamp, one for open door alarm. |
| 6 | Smoke Sensor | 1 | PC | |
| 7 | Water Sensor | 1 | PC | |
| 8 | Temperature and Humidity Sensor | 1 | PC | |
| 9 | LED Lamp | 1 | PC | DC48V |
| 10 | Power Distribution Unit | 1 | Set |
Grade B Lightning Proof AC Input: 63A/2P *1; AC Output: 16A/1P*4; |
| 11 | Rectifier System | 1 | Set |
DC48V, 90A |
| 12 | Package | 1 | Set | Wooden Case |
5. Features
6. Cabinet Dimension Drawing
7. Description
Cabinet surface coating is outdoor special powder coating, with white gray color (PANTONE 428C). The coating complies with GB/T 3181-2008 requirement.
Feeder cable and other external cables all use bottom wiring method.
