Air Conditioner For Outdoor Telecom Cabinet
Product Details
1500W Telecom Enclosure Cooling System
,Outdoor Telecom Cabinet AC
,Air Conditioner For Outdoor Telecom Cabinet
Product Description
The EC series air conditioner is applied in AC powered outdoor cabinets. The cooling range is 400W~ 5000W.
Many other series products for outdoor cabinets and base station usage could be supplied, such as DC air conditioner, HC combo air conditioner with heat pipe.
Product Features
The EC15HDNC1J is a compact, high efficient AC powered air conditioner. The design is optimized for applications with limited space available, but where functionality and performance still cannot be compromised.
220VAC power input
1500W cooling capacity@L35/L35
Door mounted easy integration in outdoor cabinets
Standard configuration with heater
Wide working temperature range: -40ºC to +55 ºC w/ heater
Benefits
Energy saving
Lifetime ＞10 years minimum maintenance
Environmental friendly R134a and RoHS compliant
IP55 and corrosion proof
Dedicated design by delay start
RS485 for remote control
Applications
Outdoor Battery Cabinets
Outdoor Radio Base Stations / Telecom Cabinets
Outdoor Power Supply Cabinets
Outdoor Gen-set Control Cabinets
Outdoor Solar Powered Telecom Cabinets
Outdoor Wind Power Control Cabinets
|
Dimensions, Weight & Mount
|
|
|
External Dimensions (H x W x D)
|
746×446×200mm
|
|
External Dimensions (H x W x D) With Flange
|
783×483×200mm
|
|
Weight
|
32kg
|
|
Mounting Method
|
Door Mounted
|
|
Application
|
Outdoor
|
|
Environmental Protection & Performance
|
|
|
Working Temperature Range
|
-40 to +55ºC
|
|
Noise Level (Indoor Side)
|
65dB(A)
|
|
IP Protection Level
|
IP55
|
|
Refrigerant
|
R134a
|
|
RoHS Compliant
|
Yes
|
|
Cooling/Heating Capacity
|
|
|
Cooling Capacity@L25/L35
|
|
|
Cooling Capacity@L35/L35
|
1500W
|
|
Heating Capacity (Optional) |
1000W
|
|
Power Consumption
|
|
|
Power Consumption@L25/L35
|
|
|
Power Consumption@L35/L35
|
600W
|
|
Current@L25/L35
|
|
|
Current@L35/L35
|
2.90A |
|
Airflow
|
|
|
Internal Airflow
|
400m3/h
|
|
Power Supply
|
|
|
Power Supply Range
|
220±15%V, 50/60Hz
|
|
Rated operating voltage - Controller
|
220V, 50/60Hz
|
|
Rated operating voltage - Cooling/Heating System
|
220V, 50/60Hz
|
|
Max. Current
|
5.5A
|
Cooling Capacity Curve
Power Consumption Curve
Dimension Diagram
-
