Product Details:
Payment & Shipping Terms:
|
| Cooling: | DC48V Air Conditioner And DC48V Fans | Other Cooling Options: | Heat Exchanger, And AC220V Air Conditioner |
|---|---|---|---|
| Cable Inlet: | At Cabinet Bottom | External Dimension: | H*W*D 1150*650*650mm |
| Structure: | Double Wall(thickness Of Outer Plate: 1.5mm, Thickness Of Inner Plate: 0.8mm) | ||
| High Light: | outdoor pole mount enclosure,pole mount cabinet,Outdoor Telecom Battery Cabinet |
||
Outdoor Pole Mount Enclosure , Telecom Battery Cabinet With DC48V Air Conditioner
1. Features
2. Quick Details:
| Place of Origin: Shenzhen, China (Mainland) | External Dimension: H*W*D 1150*650*650mm |
| Brand Name: ESTEL | Structure: double wall, with insulation, sandwich structure |
| Model Number: DDTE050/03 | Cabinet Layout: one compartment, for installing batteries and equipment |
| Product Name: Pole Mount Enclosure | Cabinet Lock: anti-theft three point lock |
| Certification: ISO9001, CE, 3C, FCC, TLC, IP55 | Protection Level: IP55 |
| Application: outdoor telecom base station | Cable Inlet: at cabinet bottom |
| Material: galvanized steel | Illumination: DC48V LED lamp |
| Heat Insulation: PEF | Grounding Protection: copper bar |
| Color: grey (support custom made) | Cooling: DC48V air conditioner and DC48V fans |
| Coating: anti-corrosion outdoor powder coating | Other Cooling Options: heat exchanger, and AC220V air conditioner |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 9,000 sets per month |
| Delivery Time: | 10-15 working days |
| Packaging Details: | wooden case |
3. Specifications
(1) Technical Parameters
| Item | Type | Technical Parameter |
| Structure | Dimension | External Dimension: H*W*D 1150*650*650mm |
| Layout | 1 compartment, the lower part is for installing batteries, and the upper part is for installing 19” equipment. | |
| Equipment Installation Method | 19” rack and battery shelf | |
| Door | With one front door, and special lock for outdoor cabinet (support padlock) | |
| Material | Galvanized steel; 1.5mm thick outer plate, 0.8mm thick inner plate | |
| Heat Insulation | There are heat insulation between inner wall and outer wall. The insulation material is 20mm PEF. | |
| Structure | Assembled | |
| Ingress Protection | IP55 | |
| Temperature Control | Cooling | DC48V air conditioner and DC48V fans |
| Lighting | LED lamp | 48V LED lamps |
| Temperature | Temperature | Working Temperature: -40°C ~ +55°C |
| Storage Temperature: -50°C ~ + 70°C | ||
| Transport Temperature: -50°C ~ +70°C | ||
| Humidity | Relative Humidity | 5% ~ 100% |
| Pressure | Air Pressure | 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude) |
| Radiation Intensity | Solar Radiation Intensity | 1120 × (1±5%)W/m2 |
(2) Accessories List
| No. | Item | Quantity | Unit | Specs |
| 1 | Outdoor Power Cabinet | 1 | Set |
(1) External Dimension: H*W*D 1150*650*650mm (2) 1 compartment, the lower part is for installing batteries, and the upper part is for installing 19” equipment. (3) With one front door , and special lock for outdoor cabinet (support padlock) ; (4) Material: galvanized steel; 1.5mm thick outer plate, 0.8mm thick inner plate; |
| 2 | Air Conditioner | 1 | Set | Cooling capacity: 500W, DC48V |
| 3 | Auxiliary Direct Ventilation Fans | 4 | PC | 12038 DC48V |
| 4 | Door Sensor | 2 | PC | One for controlling LED lamp, the other for open door alarm |
| 5 | LED Lamp | 1 | PC | DC48V |
| 6 | Package | 1 | Set | Wooden Case |
4. Description
4.1 Cabinet Dimension Diagram
4.2 Cabinet Layout Diagram
4.3 Grounding copper bar and cable entrance hole
(1) Damage resistance of the theft proof lock meets GA/T 73-1994 “Mechanical Anti-theft Lock” class B requirement, supporting padlock.
