Custom Environment Monitoring System Spot-Type Photoelectric Smoke Sensor Detector
Product Details
environmental monitoring systems
,environmental monitoring unit
Custom Environment Monitoring System Spot-Type Photoelectric Smoke Sensor Detector
Quick Details
| Place of Origin: Shenzhen, China (Mainland) | Power Supply: DC 12(8~28)V |
| Brand Name: ESTEL | Monitoring Current:<0.7mA(12V) |
| Product Name: Smoke Sensor / Detector | Fire alarm Current: <65mA(12V) |
| Model Number: JTY-GD-T12(ZN) | Alarm Volume: >80dB (front 3m) |
| Certification: ISO9001, CE, 3C, FCC, TLC | Dimension: Diameter 120mm × Height 36mm |
| Application: Outdoor Telecom Cabinet | Outlet Contact Capacity: 0.3A/60VAC, 1A/30VDC |
Shell Material& Color: ABS white | Standards: GB4715-2005 |
Payment & Shipping Terms
| Minimum Order Quantity: | 1 set |
| Price: | negotiation |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 50,000 sets per month |
| Delivery Time: | 7-10 working days |
| Packaging Details: | carton/wooden case |
1. Description
JTY-GD-T12 smoke detector (detector) can provide protection for communication and electric BTs, and exactly detect smoke. When the concentration of smoke exceeds the preset threshold, the detector alarms and send alarm signal to the control panel. With high volume buzzer, the detector gives high volume sound. The alarm signal doesn’t lock-up, when the density of smog is below the preset threshold, the detector resumes monitoring state. With perfect thunder-proof circuit, the detector can operate normally at bad environment.
2. Specification
Technical Parameter
Power supply: DC 12(8~28)V
Monitoring current:<0.7mA(12V)
Fire alarm current: <65mA(12V)
Method of output: Relay no source output, output short circuit in monitoring, output open circuit in alarm(User can set it)
Outlet contact capacity: 0.3A/60VAC, 1A/30VDC
Indicator: (Tri-color) Green: normal, red: fire alarm, yellow: trouble
Alarm volume: >80dB (front 3m)
Operating temperature: -10℃~+50℃
Operating humidity: ≤95%RH (40℃±2℃ noncondensing)
Protected area: 60 m2 at the height below 6m (radius≤5.8m)
80 m2 at the height within 6-12m (radius ≤ 6.7m)
Usage time limit: >10 years
Dimension: Diameter 120mm × Height 36mm
Shell material& color: ABS white
Weight: 110g
Hole distance: 92mm
Standards that apply: GB4715-2005
3. Structural characteristics and working principle
(1) Shape of detector (Figure 1)
(2) Shape and structure (Figure 2)
(3) Inside of detector (Figure 3)
4. Packing and Shipping
Our Delivery Agent
The goods can be shipped by sea, by air, by courier, by land, by train, etc.
Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.
