Outdoor cabinets are used in a wide range of applications where equipment needs to be stored and protected in outdoor environments. Some of the common applications for outdoor cabinets include:

1. Telecommunications: Outdoor cabinets are often used to house equipment for telecommunications networks, such as base station equipment, fiber optic equipment, and power supplies.
2. Security: Outdoor cabinets can be used for security applications, such as housing surveillance cameras, access control systems, and alarm systems.
3. Energy and utilities: Outdoor cabinets are commonly used to store equipment for energy and utility companies, such as transformers, switchgear, and control equipment.
4. Transportation: Outdoor cabinets can be used in transportation applications, such as traffic control systems, toll booths, and railway signaling equipment.
5. Industrial: Outdoor cabinets are commonly used in industrial applications, such as housing control equipment for manufacturing processes or storing equipment for oil and gas exploration.
6. Emergency services: Outdoor cabinets can be used for emergency services, such as housing equipment for emergency medical services or storing equipment for disaster response teams.
7. Agriculture: Outdoor cabinets can be used in agriculture applications, such as storing equipment for irrigation systems or controlling the temperature in greenhouses.

Overall, outdoor cabinets are designed to provide a secure and protected environment for equipment that needs to be stored and operated in outdoor environments. The cabinets are built to withstand harsh weather conditions, protect against theft and vandalism, and provide proper ventilation and insulation to keep equipment functioning properly.

1. Outdoor Communications Cabinet Specifications:

 Technical Parameters

(1) External Dimension H1700×W900×D900mm

(2) One compartment

(3) Equipment Installation Method : 19” standard rack

(4) With one front door, and anti-theft three point lock for outdoor cabinet (support padlock)

(5) Material : 1.2mm single wall galvanized steel with heat insulation

(6) Structure Assembled

(7) Ingress Protection IP55

(8) Cooling with AC220V Air Conditioner and DC48V fans

(9) LED lamp: 48V LED lamp

(10) Temperature Working Temperature: -40°C ~ +55°C

(11) Storage Temperature: -50°C ~ + 70°C

(12) Transport Temperature: -50°C ~ +70°C

(13) Relative Humidity 5% ~ 100%

(14) Air Pressure :62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)

(15) Solar Radiation Intensity:1124 × (1±5%)W/m2

Accessories List

2. Outdoor Communications Cabinet Features

• Fully welded design; supplied complete, ready to go
• Lockable front door
• Rain hood included
• Sealed bottom cable entry gland
• Adjustable 19” mounting rails front and rear
• Grounding bar
• Front door rubber seal
• Cabinet design allows natural wind cooling through filtered vents on front door
• All fixings are internal to the cabinet to provide a secure solution
• Come with plinth for mounting on the floor ground, with cable gromments for the cabling
• Available in colours, Grey, Green or customized colors

3. Some more Technical Specs

(1)  Applicable environment conditions:

Environment temperature: -40°C ~ + 70°C

Environment humidity (RH): ≤95% (at + 40°C)

Air pressure: 62kPa ~ 102kPa

• Material: good quality galvanized steel

• Surface treatment: degreasing, derusting, rustproof phosphating (or galvanizing), powder coated.

• Cabinet load bearing: ≥600kg

• Ingress protection: IP55

• Flame retardance: comply with GB5169.7 test A

• Insulation resistance: the insulation resistance between grounding devices and cabinet body parts is not lower than 2X104M/500V(DC).

• Withstand voltage: the withstand voltage between grounding devices and cabinet body parts is not lower than 3000V(DC)/1min.

• Mechanical strength: each surface can bear upright pressure＞980N; after the door is open, its outer end can bear upright pressure ＞200N.

4. Outdoor Communications Cabinet diagram

5.Sensors Installation

•  LED lamp, smoke sensor and door sensor are installed at the top of the cabinet.

• Water sensor is installed at the bottom of the cabinet.

• Temperature and humidity sensor is installed at the side inside the cabinet.

6.Wire Routing Design

Feeder cable and other external cables all use bottom wiring method.

7.Grounding Protection

• The cabinet includes grounding copper bar with anti-corrosion coating. There are enough screws for wiring connection terminals.

• The metal part of the cabinet should be interconnected and be connected with grounding bar. Connection resistance between any two points is lower than 0.1Ω.

• Protective earthing of other equipments inside the cabinet should be connected to the grounding bar.

8. Connection and Fastening

(1)  Use anti-loose threaded connection as structure and bearer connection. Anchor bolt for fixing cabinet use hot dip galvanized bolts.
(2)  Door hinges use inner hinge mode.

9. Appearance and Surface Treatment

Cabinet surface coating is outdoor special powder coating, with white gray color (PANTONE 428C). The coating complies with GB/T 3181-2008 requirement.


10. Cabinet Installation


Position of installation holes at cabinet base are as follows:




Users prefabricate concrete base.

Pre-embed 4pcs M10×120 anchor bolts on the concrete base. Distance between bolts are as that in diagram 1. Bolt exposed height is 40mm. Put the cabinet on the concrete base, align anchor bolts, then screw on nuts, and tighten them with wrench.

According to site situation, put the cabinet on the concrete base with forklift, crane or manually, and fix it on the concrete base with bolts.

11. PDU Principle Diagram For this Cabinet
