IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel

IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel
IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel

Large Image :  IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel

Product Details:
Place of Origin: China
Brand Name: ESTEL
Certification: ISO9001
Model Number: ET9090215-EQ
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Packaging Details: Wooden Case with Pallet
Delivery Time: 15 to 20 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1800PCS per month
Detailed Product Description
Dimension: W×D×H 900×900×2150mm Cabinet Layout: One Compartment: 19” 42U
Material: Galvanized Steel, Single Wall Without Insulation Cooling System: Fan
Working Temperature: -40°C ~ +75°C Relative Humidity: 5% ~ 100%
Door Lock: Outdoor Anti-theft Three Point Lock Cable Entry: On The Bottom
Surface Treatment: High Anti-corrosion Powder Coating IP Level: IP55
High Light:

42U Telecom Equipment Cabinet

,

IP55 Telecom Equipment Cabinet

,

42U outdoor equipment cabinet

IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel



42U Single Layer Galvanized Steel IP55 Fan Cooling Telecom Equipment Cabinet Outdoor Communication Enclosure



1. Application


The ET9090215-EQ Outdoor Telecom Cabinet is mainly used in wireless communication base station, such as 4G system, communication/network integrated service, access/transmission switching station, emergency communication/transmission, etc.


2. Description


This cabinet have 42U space, use galvanized steel material, one front door. Adopt fan for cooling. All the screw is high corrosion resistance stainless steel material.


3. Features


(1) The cabinet is dustproof, sunproof fireproof and rainproof, which is used in outdoor environment.
(2) Cabinet cooling: fans. (Other cooling option: heat exchanger and air conditioner). MTBF≥50000h
(3) The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding. There are cable inlet individually for power cable, signal cable and optical cable.
(4) All the cables used in the cabinet are made from flame retardant materials.
(5) Use outdoor powder coating with high anti-corrosion.


4. Technical Parameters





Item Type Technical Parameter
Structure Dimension

External Dimension: W×D×H 900×900×2150mm

(19”, 42U)

Layout 1 compartment
Equipment Installation Method 19” rack
Door With one front door, and anti-theft three point lock for outdoor cabinet (support padlock).
Material Galvanized steel, single wall without insulation
Ingress Protection IP55
Temperature Control Cooling AC220V Fans
Lighting LED lamp AC220V LED lamp
Temperature Temperature Working Temperature: -40°C ~ +75°C
    Storage Temperature: -50°C ~ + 70°C
    Transport Temperature: -50°C ~ +70°C
Humidity Relative Humidity 5% ~ 100%
Pressure Air Pressure 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
Radiation Intensity Solar Radiation Intensity 1120 ×(1±5%)W/m2



5. Accessories List





No. Item Quantity Unit Specs
1 Outdoor Telecom Cabinet 1 PC

(1) External Dimension: W×D×H 900×900×2150mm

(2) One compartment: 19” 42U

(3) With one front door, and anti-theft three point lock for outdoor cabinet (support padlock).

2 Fan 1 SET Two AC220V fans with one temperature contoller
3 LED Lamp 1 PC AC220V, for illumination inside cabinet
4 LED Lamp Switch 1 PC For controlling LED lamp on/off
5 Package 1 PC Wooden Case



6. Cabinet Dimension
External Dimension: W×D×H 900×900×2150mm
(19” 42U)



IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel 0




7. Similar Cabinet Picture



IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel 1




8. Our factory and certificate



IP55 42U Telecom Equipment Cabinet Single Layer Galvanized Steel 2
