IP55 19" Rack Heat Insulation Outdoor Communication Cabinets
  • IP55 19
  • IP55 19
  • IP55 19
  • IP55 19

IP55 19" Rack Heat Insulation Outdoor Communication Cabinets

Place of Origin Shenzhen, China (Mainland)
Brand Name ESTEL
Certification ISO9001, CE, 3C, FCC, TLC, IP55
Model Number 121070717050003
Product Details
Galvanized Steel,single Wall With Heat Insulation
Protection Level:
Cooling System:
2 Fans
One Compartment
Cabinet Door:
One Front Door
Cable Entry:
From Cabinet Bottom
Door Lock:
Anti-theft Three Point Lock
High Light:

19" Rack Outdoor Electronics Cabinet


IP55 Outdoor 19 Rack Enclosure

Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
Wooden case
Delivery Time
15-20 working days
Payment Terms
T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability
8,000 sets per month
Product Description

IP55 Dustproof Electronical Cabinet Galvanized Steel Heat Insulation


1. Cabinet Features


1.1 External Dimension is W×D×H 750×750×1750mm

1.2 Galvanized steel,single wall with heat insulation

1.3 Anti-theft three point lock

1.4 The cabinet includes 19” standard installation rack.

1.5 The cabinet cooling uses 2 fans.

1.6 Including -48VDC illumination lamp.

1.7 The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding.

1.8At the bottom of the cabinet, there are entrance holes individually for power cable, signal cable and optical cable.

1.9 The cabinet is dustproof, sunproof and rainproof, which is used in outdoor environment.

1.10 All the cables, sealing and heat insulation used in the cabinet are made from flame retardant materials, which comply with GB5169.7 test A

1.11 IP55 protection level.


2. Cabinet Parameters


Item Type Technical Parameter
Structure Dimension

External Dimension W×D×H 750×750×1750mm

Layout One compartment
Equipment Installation Method 19” standard rack
Door With one front door with three point lock for outdoor cabinet (support padlock)

Galvanized steel,single wall with heat insulation

Structure Assembled
Ingress Protection IP55
Temperature Control Cooling 2 fans
Lighting LED lamp 48V LED lamp
Temperature Temperature Working Temperature: -40°C ~ +55°C
Storage Temperature: -50°C ~ + 70°C
Transport Temperature: -50°C ~ +70°C
Humidity Relative Humidity 5% ~ 100%
Pressure Air Pressure 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
Radiation Intensity Solar Radiation Intensity 1124 × (1±5%)W/m2


3. Components Installation


3.1  PDU is installed on 19” rack.

Class B lightning protection: 60KA*1;

AC Input: 63A/2P*1;

AC Output: 16A/1P*4;

DC Output: 16A/1P*4;

Input Voltage: AC220V 50Hz.


IP55 19" Rack Heat Insulation Outdoor Communication Cabinets 0


3.2 The cabinet cooling uses 2 fans,insatlled on the front door


4. Cable Inlet


All feeder cable and other external cables all use bottom wiring method.

There are 4 cable inlets at the bottom of the cabinet.


IP55 19" Rack Heat Insulation Outdoor Communication Cabinets 1


5. Cabient Packing


IP55 19" Rack Heat Insulation Outdoor Communication Cabinets 2


6. Our Delivery Agent


The goods can be shipped by sea, by air, by courier, by land, by train, etc.

Besides the following delivery agent, we can also look for the delivery agent with the best price in china if you need us to do for you.
