|External Size:||W× D×H 650 ×650 ×1300mm||Cabinet Lock:||Anti-theft Three Point Lock(support Padlock)|
|Cable Inlets:||From Cabinet Bottom||Mounting Type:||Floor Mount|
|Cooling System:||Air Conditioner And Fans||Protection Level:||IP55|
telecom equipment cabinet,
outdoor telecom enclosure
24U Galvanized Steel Outdoor Telecom Cabinet IP55 Air Conditioner & Fans Cooling System
The ET6565130-EQ Outdoor Cabinet is mainly used in wireless communication base station, such as communication/network integrated service, access/transmission switching station, emergency communication/transmission, etc.
(1) The cabinet is dustproof, sunproof and rainproof, used in outdoor environment.
(2) Cooling: air conditioner and fan.
(3) The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding.
(4) All the cables used in the cabinet are made from flame retardant materials.
3. Technical Parameters
|Structure||Dimension||External Size H*W*D 1300*650*650mm|
|Layout||One compartment, used for installing 19” equipment|
|Equipment Installation Method||19” rack|
|Door||With one front door and one back door, and anti-theft three point lock for outdoor cabinet (support padlock)|
|Material||Galvanized steel, single wall with thermal insulation|
|Temperature Control||Cooling||Air conditioner and fans|
|Temperature||Temperature||Working Temperature: -40°C ~ +55°C|
|Storage Temperature: -50°C ~ + 70°C|
|Transport Temperature: -50°C ~ +70°C|
|Humidity||Relative Humidity||5% ~ 100%|
|Pressure||Air Pressure||62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)|
|Radiation Intensity||Solar Radiation Intensity||1120 × (1±5%) W/m2|
4. Accessories List
|1||Outdoor Telecom Cabinet||1||Set||
(1) External Dimension
H×W×D 1300× 650× 650mm.
(2) One compartment: including 24U 19” rack.
(3) With one front door and one back door, with three point lock for outdoor cabinet.
(4) Material: galvanized steel, single wall with thermal insulation.
Cooling Capacity: 500W
Power Supply: 220VAC, 50Hz
|4||LED Lamp Switch||1||PC||For controlling LED lamp on/off|
5. Cabinet Drawing
External Dimension H×W×D 1300×650×650mm(19”, 24U).
6. Lock Theft Proof Design
(1) Damage resistance of the theft proof lock meets GA/T 73-1994 “Mechanical Anti-theft Lock” class B requirement, supporting padlock.
(2) Three point lock
