| Ingress Protection: | IP55 | Input Voltage: | AC220V±15% 50Hz |
|---|---|---|---|
| Cooling Capacity L35/L35: | 3000W | Refrigerant: | R134A |
| Weight: | 25kg | Noise: | 60dB |
| High Light: | electrical enclosure air conditioner,server cabinet air conditioner,Outdoor Enclosure Air Conditioner 3000W |
||
3000W Cooling Capacity R134A Refrigerant Kiosk Air Conditioner
1. Technical Parameters
Designed for outdoor advertising machine cooling, easy to install, good air conditioning duct system design, effectively solve the high temperature black screen phenomenon;
Low noise, anti fouling, IP55 protection, etc;
Working environment range: - 40～+ 55 ℃;
Multi function alarm output and RS485 communication function;
Adopt famous brand industrial parts with high reliability;
Fast man-machine interface operation, real-time temperature display,automatic precision Ensure temperature control.
2. Product Key Parameters
| Item | Name | Unit | Parameter |
| Dimension and installation | Body outline dimension (width*height*depth ) | mm | 784*619*245 |
|
Outline dimension including flange(width*height*depth ) |
mm | / | |
| Weight | Kg | 40 | |
| Installation method | Door Mounted | ||
| Installation method | Outdoor | ||
| Environment and protection | Working environment temperature | ℃ | -40 to +55 |
| Noise | dB(A) | 65 | |
| Life expectancy | Years | >10 | |
| IP grade | IP55 | ||
| Refrigerant | R134a | ||
| ROHS certification | yes | ||
| Performance | Input voltage range | 220 VAC±15% ～/50Hz | |
| Refrigerating capacity(L35/L35) | W | 3000 | |
| Rated Refrigerating input power(L35/L35) | W | 1280 | |
| Rated Refrigerating current (L35/L35) | A | 5.8 | |
| Maximum Refrigerating current | A | 8.5 | |
| Heat capacity(optional) | W | 1000 | |
| Air Volume of Inner Circulation | m3/h | 900 | |
3. Product Dimensions
