Dual Compartment Outdoor Rack Mount Enclosure Weatherproof With PDU EMS UPS Optional

Dual Compartment Weatherproof Air Conditioner Cooling Outdoor Enclosure With PDU EMS UPS Optional

1. Dual Compartment Outdoor Cabinet Description

Double Bay Outdoor Enclosure is available in a variety of configurations, and they can be used in several different applications. The Cabinet is an outstanding robust, cost effective, long service life solution for domestic and international projects. Custom widths, lengths and configurations are also available. It can support Equipments, Batteries, Environment Monitor Unit, PDU and etc. Ultimate security is provided by a three-point locking system. This series enclosures offer all the protection needed for outdoor requirements.

2. Dual Compartment Outdoor Cabinet Features

2.1Dimensions: W*D*H 1600*800*2000mm,

2.2 Dustproof, Sunproof and Rainproof.

2.3 Standard 19” Rack Mountable Equipment.
2.4 Layout : 2 compartments (separated left compartment and right compartment), with middle division plate.

2.5 Electrical Grounding bar inside.

2.6 Doors: Lockable, With 2 front doors, and anti-theft 3-point lock with padlock optional.

2.7 Installation mode: installed on a concrete floor.

2.8 Heat Insulation: 20mm PEF heat insulation between inner wall and outer wall.

2.9 Cabling mode: routed in and out from the bottom.

2.10 Including -48VDC illumination lamp.

2.11 Accessories: PDU, Monitor, Light, Alarm Sensors (Based on request),Batteries.

2.12 Temperature Control: AC220V air conditioner or DC48V fans.

2.13 Protection level:IP55.

2.14 Certificates:CE.

3. EMS Instruction

EMS is a network monitoring host designed for integrated network rooms that integrates UPS monitoring and extended power environments. Adopting the popular 19-inch rack-mount design style, supporting 220V AC or 48V DC power supply, supporting more than 12-way switching value, multi-way relay control output and ambient temperature and humidity expansion, with SMS monitoring and control functions, more secure and more reliable. It will be the best choice for modern unmanned duty rooms.

The monitoring functions implemented by the supporting sensors are as follows:

•  Multi-brand UPS monitoring
•  Up to 8 channels of temperature and humidity detection
•  Water leakage (water immersion) test
•  Fire smoke detection
•  Infrared passive intrusion detection
•  Door m agnetic (opening) detection
•  Power distribution air switch state detection
•  Mains power input state detection.
•  Electricity quantity acquisition and measurement

5. Shippment

6. Our Factory Instruction

Factory Size: 3000 Square Meters

No. of Main Production Lines: 5

Contract Manufacturing: OEM Service Offered, Design

Service Offered, Buyer Label

offered

Production Experience: 13 Years

7. Leading Time

Usually about 15-20 days. The exact lead time need to be confirmed according to the quantity of order.
