| Place of Origin | Shenzhen, China (Mainland) |
| Brand Name | ESTEL |
| Certification | ISO9001, CE, 3C, FCC, TLC, IP55 |
| Model Number | 342060618050001 |
Sandwich Steel IP55 Outdoor Telecom Cabinet Front Rear Access With 1 Unit PDU
1. Cabinet Description
This series IP55 Outdoor cabinet with rear back access offers the ideal enclosure solution to build the whole base station inside.The cabinets system can support Electrical equipments,PDU,Backup batteries,Mornitoring system and etc.This series enclosures offer all the protection needed for outdoor requirements.Ultimate security is provided by a three-point locking system.
2. Cabinet Features
| External Size | W*D*H 600*600*1800mm |
| Mounting type |
Floor mount |
| Material |
Sandwich steel ,double wall with insulation |
|
Cabinet Layout |
One compartment |
|
Door limit |
Door limit up to 110 degree open angle |
|
Protection Level |
IP55 |
| Cabinet Inlets | From cabinet bottom |
| Illumination | DC48V LED lamp |
| Grounding Protection | Copper bar |
| Color | Grey (support custom made) |
| Coating | Anti-corrosion outdoor powder coating |
| Alarm sensors |
The door sensor, water sensor, smoke sensor, temperature and humidity sensor |
| Flame retardant | Comply with GB5169.7 test A |
| Door type |
With one front door and one back door anti-theft 3hree point lock for outdoor cabinet (support padlock). |
| Cabinet Lock | Anti-theft three point lock(support padlock) |
| Package | Wooden case with pallets |
| Certificates | CE |
3. Cable Entry Holes
There are entrance holes individually for power cable, signal cable and optical cable from cabinet bottom.
4. Cabinet connection and fastening
(1) Use anti-loose threaded connection as structure and bearer connection.Anchor bolt for fixing cabinet use hot dip galvanized bolts.
(2) Door hinges use inner hinge mode.
5. Grounding Protection
The cabinet includes grounding copper bar with anti-corrosion coating. There are enough screws for wiring connection terminals.
The metal part of the cabinet should be interconnected and be connected with grounding bar. Connection resistance between any two points is lower than 0.1Ω.
Protective earthing of other equipments inside the cabinet should be connected to the grounding bar.
6. Leading Time
Usually about 10-15 days. The exact lead time need to be confirmed according to the quantity of order.
