IP65 Two Doors Sunproof Rainproof Aluminium Floor Mount Outdoor Telecom Cabinet
Product Details
outdoor communication cabinets
,outdoor telecom enclosure
,Rainproof Outdoor Telecom Cabinet
IP65 Two Doors Sunproof Rainproof Aluminium Floor Mount Outdoor Telecom Cabinet
1. Product Overview
Two doors sunproof rainproof aluminium outdoor cabinet offers the ideal enclosure solution to build the whole base station inside ,It provides flexible size options, The cabinets system can support different kinds of electrical equipments based on custom needs.The IP protection is IP65.
2. Specifications
| External Size | W*D*H 1550*400*1250mm |
| Mounting type |
Floor mounting type |
| Material |
Single layer aluminum sheet,2.5mm thick |
|
Cabinet Layout |
One compartment for installing equipment |
|
Cabinet Doors |
With 2 front door, and anti-theft three point lock for outdoor cabinet (support padlock). |
|
Equipment Installation Method |
The equipment installed on the back panel inside the cabinet. |
|
Protection Level |
IP65 |
| Cabinet Inlets | From cabinet bottom |
| Illumination | DC48V LED lamp |
| Grounding Protection | Copper bar |
| Color | Grey , RAL7035 |
| Coating | Anti-corrosion outdoor powder coating |
| Alarm sensors | The door sensor, water sensor, smoke sensor, temperature and humidity sensor |
| Flame retardant | Comply with GB5169.7 test A |
| Cabinet Lock | Anti-theft three point lock(support padlock) |
| Package | Wooden case with pallets |
| Certificates | CE |
3. Equipment installation method
The equipment installed on the back panel inside the cabinet.
4. Theft Proof Design
4.1 Three theft lock theft proof design
Damage resistance of the theft proof lock meets GA/T 73-1994 "Mechanical Anti-theft Lock"class B requirement,supporting padlock.
4.2 Connection and fastening
(1) Use anti-loose threaded connection as structure and bearer connection.Anchor bolt for fixing cabinet use hot dip galvanized bolts.
(2) Door hings use inner hinge mode.
5. Factory Introduction
Factory Size: 3000 Square Meters
No. of Main Production Lines: 5
Contract Manufacturing: OEM Service Offered, Design Service Offered, Buyer Label Offered
Production Experience: 13 Years
6. Leading Time
Usually about 10-15 days. The exact lead time need to be confirmed according to the quantity of order.
