R134A Refrigerant Kiosk Air Conditioner
Basic Properties
Place of Origin:
Shenzhen, China (Mainland)
Brand Name:
ESTEL
Certification:
ISO9001, CE, 3C, FCC, TLC, IP55
Model Number:
EGA0600/A1
Trading Properties
Minimum Order Quantity:
1 set
Price:
215-1215 usd
Payment Terms:
T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability:
8,000 sets per month
Product Summary
Kiosk Air Conditioner 220VAC 600W Cooling Capacity With 500W Heating Capacity IP55 1. Product Parameters Type Parameters Dimensions(Without flange) 638*450*158.4mm Weight 18.5 kg Mounting method Door mounted Working temperature -40℃ -55 ℃ Input voltage 220 VAC±15% ～/50Hz Cooling capacity L35/L35 600 ...
Product Details
Highlight:
outdoor enclosure air conditioner
,server cabinet air conditioner
,Kiosk Air Conditioner 220V AC
Ingress Protection:
IP55
Input Voltage:
AC220V±15% 50Hz
Cooling Capacity l35/l35:
600 W
Heating Capacity:
500W
Weight:
18.5kg
Refrigerant:
R134A
Product Description
Kiosk Air Conditioner 220VAC 600W Cooling Capacity With 500W Heating Capacity IP55
1. Product Parameters
| Type | Parameters |
| Dimensions(Without flange) | 638*450*158.4mm |
| Weight | 18.5 kg |
| Mounting method | Door mounted |
| Working temperature | -40℃ -55 ℃ |
| Input voltage | 220 VAC±15% ～/50Hz |
| Cooling capacity L35/L35 | 600 W |
|
Rated Refrigerating input power(L35/L35) |
350W |
| Rated Refrigerating current (L35/L35) | 1.6A |
| Heating capacity | 500W |
| Airflow | 240 m3/h |
| IP grade | IP 55 |
| Refrigerant | R134A |
| Noise | 60 dB(A) |
2. Product Installation
3. Product Pictures
