19" Thermostatic Outdoor Telecom Cabinet 34U Temperature Control Powder Coat

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  19" Thermostatic Outdoor Telecom Cabinet 34U Temperature Control Powder Coat

Product Details:
Place of Origin: China
Brand Name: ESTEL
Certification: ISO9001
Model Number: ET9090180-EQ
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Packaging Details: Wooden Case with Pallet
Delivery Time: 15 to 20 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1800PCS per month
Detailed Product Description
Material: Sandwich Strucure Panel, Galvanized Steel, Double Wall With Heat Insulation External Dimension: Height *width *depth 1800*900 *900mm
Available User Space: 34U Standard 19” Rail Cable Entry: Located On The Bottom, Front Door And Back Wall
IP Level: IP55 Screw: Stainless Steel Material
Cooling Method: Air Conditioner And Fan Package: Plywood Box
High Light:

Thermostatic Outdoor Telecom Cabinet

,

34U Outdoor Telecom Cabinet

,

34U outdoor telecom enclosure

19" Thermostatic Outdoor Telecom Cabinet 34U Temperature Control Powder Coat



19" Equipment Rack Mount Thermostatic Outdoor Telecom Cabinet 34U Temperature Control Communication Cabinet Powder Coat



1. Application field of outdoor telecom cabinet


Our outdoor telecom cabinet is widely used in many areas, such as below:
Telecommunication
Power
Energy
Solar
lndustry
Radio and television
Bank
Education
Traffic
Security monitoring
Automatic system
Research institute


2. Outdoor Cabinet Parameter



No. Description Specification
Specification of cabinet
1 Model ET9090180-EQ
2 Dimension Height *width *depth 1800*900 *900mm
3 Available User Space 34U standard 19” rail
4 Door One front door
5 Lock Outdoor special anti-theft three point lock(can support padlock)
6 Material Sandwich strucure panel, galvanized steel, double wall with heat insulation
7 Processing Laser cutting, CNC punching, CNC bending, welding, stamping, etc
8 Surface treatment Surface spraying special outdoor cabinet powder
9 Cabinet Installation method Floor mount,can fix the cabinet on the concrete plinth
10 Cable Entry Located on the bottom, front door and back wall
11 Lifting 4 hooks on the cabinet base
12 Earthing Grounding copper bar
13 Screw Stainless steel material
14 Working Temperature -40°C~+75°C
15 Protection Level IP55
16 Relative Humidity 5% ~ 100%
17 Atmospheric Pressure 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
18 Withstand Voltage >3000VDC/min and no breakdown fly arc
19 Solar Radiation Intensity 1120 ×(1±5%)W/m2
Electric device
1 Cooling

Air conditioner

Cooling capacity: 1500W,

Power supply: AC220V

2 Fan 2 AC220V fans with 1 temperature controller
3 LED light AC220V with LED lamp switch
Packing
Plywood box W×D×H 1200×1050×2100mm



3. Feature


(1)The embedded structure door enhances the anti-theft effect.
(2)High quality hot dip galvanized steel.
(3)Standard 19 inch rack, 4 posts.
(4)High protection level IP55, waterproof and dustproof, effectively protect the equipment in the cabinet.
(5)Outdoor anti-corrosion powder coating
(6)Three-point theftproof lock.
(7)Air conditioner and fan cooling
(8)Hidden hinge, inside screws, enhance the theftproof.
(9)Door limit to hold door open at service.
(10)Flexible cable entry
(11)High reliability, maintenance-free, fast assembly, suitable for harsh environment
(12)High integration, small footprint, short construction period, reduce the construction cost
(13)Support for fast assembly, ready for the summit, multi-scene roof installation


4. Our strengths



  • Original manufacturer
  • Our steel material comes from famous big factory providing best quality assurance
  • Professional technical team and quality inspection team
  • Support custom made based on customer’s different application requirements
  • Professional shipping team, make full use of space and save your transportation cost



5. Cabinet display



19" Thermostatic Outdoor Telecom Cabinet 34U Temperature Control  Powder Coat 0








6. Packing


Our cabinets are packed in wooden box which is a kind of free fumigated plywood.The advantage is rain proof, moisture-proof, mildew proof, rust proof, erosion proof, dust-proof, shock proof, local protection, etc. It can protect the goods reliably. Firm and reliable, compact packaging, reduce the loss of goods in the logistics process, ensure the safety of goods; goods can be effectively protected, which is particularly important for fragile and valuable goods.



19" Thermostatic Outdoor Telecom Cabinet 34U Temperature Control  Powder Coat 1




7. Our Factory



19" Thermostatic Outdoor Telecom Cabinet 34U Temperature Control  Powder Coat 2
