Galvanized Steel One Front Door IP55 Outdoor Telecom Cabinet

small.img.alt small.img.alt small.img.alt

Large Image :  Galvanized Steel One Front Door IP55 Outdoor Telecom Cabinet

Product Details:
Place of Origin: Shenzhen, China (Mainland)
Brand Name: ESTEL
Certification: ISO9001, CE, 3C, FCC, TLC, IP55
Model Number: 111090921050003
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden case
Delivery Time: 15-20 working days
Payment Terms: T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability: 8,000 sets per month
Detailed Product Description
Material: Galvanized Steel,single Wall Protection Level: IP55
Cooling System: 2 Fans Structure: One Compartment
Cabinet Door: One Front Door Cable Entry: From Cabinet Bottom
Door Lock: Anti-theft Three Point Lock Certificates: CE
High Light:

IP55 Outdoor Communication Cabinets


Galvanized Steel Outdoor Network Enclosure


IP55 Waterproof Galvanized Steel Outdoor Telecom Cabinet One Front Door


1. Cabinet Description


This cabinet is made of high quality galvanized steel. It is Waterproof, dustproof, and corrosion resistance, provides flexible size options, offers the ideal enclosure solution to build the whole base station inside. The cabinet system can support Electrical equipments, Mornitoring system and etc.


2. Cabinet Parameters


Items Type Technical Parameter
    1 External dimensions

W*D*H 900*900*2100mm

    2 Material Galvanized steel,single wall
    3 Structure: One compartment
    4 Cooling system 2 fans,installed on the top cover
    5 Heat Insulation There are heat insulation on the outer wall.
    6 Alarm Sensors Water sensor, Door sensor, Smoke sensor, Temperature sensor and Humidity sensor
    7 Lamp DC48V LED lamp
    8 Protection level IP55
    9 Flame retardance Comply with GB5169.7 test A
   10 Temperature

Working Temperature:-40°C ~ +55°C

Storage Temperature:-50°C ~ + 70°C

Transport Temperature:-50°C ~ +70°C

   11 Package Wooden case with pallet
   12 Certificates CE


3. Cabinet Features


3.1 External Dimension is W*D*H 900*900*2100mm

3.2 Galvanized steel with heat insulation

3.3 Anti-theft three point lock

3.4 The cabinet includes 19” standard installation rack.

3.5 The cabinet cooling uses 2 fans

3.6 Including -48VDC illumination lamp.

3.7 The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding.

3.8At the bottom of the cabinet, there are entrance holes individually for power cable, signal cable and optical cable.

3.9 The cabinet is dustproof, sunproof and rainproof, which is used in outdoor environment.

3.10 All the cables, sealing and heat insulation used in the cabinet are made from flame retardant materials, which comply with GB5169.7 test A

3.11 IP55 protection level.


4. Cabinet Cooling


There are 2 fans installed on the top cover of the cabinet.


Galvanized Steel One Front Door IP55 Outdoor Telecom Cabinet 0


5. Cable Inlet


There are six cable inlets at the bottom of the cabinet.


Galvanized Steel One Front Door IP55 Outdoor Telecom Cabinet 1


6. Grounding Protection


6.1The cabinet includes grounding copper bar with anti-corrosion coating. There are enough screws for wiring connection terminals.

6.2The metal part of the cabinet should be interconnected and be connected with grounding bar. Connection resistance between any two points is lower than 0.1Ω.

6.3Protective earthing of other equipments inside the cabinet should be connected to the grounding bar.


Galvanized Steel One Front Door IP55 Outdoor Telecom Cabinet 2


7. Quality Control


7.1Our company resolutely implements the principle of quality first, we control and supervise the whole production process in strict accordance with the requirements of the ISO9001 system and the related implementation process.

7.2The quality department strictly controls all aspects like material inspection, production processes, product testing, shipment inspection and establishes traceable documents and product identification.

7.3Our quality inspection team, is very familiar with the various standards, strict implementation of the standards required sampling and testing methods.


Galvanized Steel One Front Door IP55 Outdoor Telecom Cabinet 3


8. Leading Time


Usually about 15-20 days. The exact lead time need to be confirmed according to the quantity of order.
