FSU PM5000TT3.0 Advanced Power Distribution Unit for Telecommunication Station with Intelligent Protocols Processing

FSU PM5000TT3.0 Advanced Power Distribution Unit for Telecommunication Station with Intelligent Protocols Processing
FSU PM5000TT3.0 Advanced Power Distribution Unit for Telecommunication Station with Intelligent Protocols Processing FSU PM5000TT3.0 Advanced Power Distribution Unit for Telecommunication Station with Intelligent Protocols Processing

Large Image :  FSU PM5000TT3.0 Advanced Power Distribution Unit for Telecommunication Station with Intelligent Protocols Processing

Product Details:
Place of Origin: China
Brand Name: Estel
Certification: CE UL FCC
Model Number: PM5000TT3.0
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: 43-1429 usd
Packaging Details: Wooden case
Delivery Time: 20-30days
Payment Terms: T/T, Western Union
Supply Ability: 5000
Detailed Product Description
Color: Black Application: 19 Inch Cabinet
Product Name: 19 Rack Mount Power Distribution Unit Pdu Rated Current: 50/60Hz
Type: Power Distribution System Operating Temperature: -10℃+75℃
Packing: 25pcs/carton Output: 6 Ways
Keyword: Rack Pdu Multiple Protection: Lightning Strike, Surge Protection
Model Name: PN1-32X30-20E6G-AV4W Pdu Type: RACK PDU
Working Altitude: Not More Than 3000 Meters Input Connections: NEMA 5-15P
Mounting Length: 1536mm Dc Output: 16A/1P×4
Warranty: 2 Years Dimensions: 17.5 X 1.75 X 2.2 Inches
Product Model: RDK-IP08M16
Highlight:

Telecommunication Station Power Distribution Unit

,

Intelligent Protocols Power Distribution Unit


FSU PM5000TT3.0 Advanced Power Distribution Unit for Telecommunication Station with Intelligent Protocols Processing

                                                                                PM5000 Field Supervision Unit

1. FSU Description

PM5000TT3.0 is a high-performance low-cost FSU (Field Supervision Unit) device
integrating Data Acquisition, intelligent protocols processing and communication
module.
As a smart DAC(Data Acquisition Controller) installed in every telecommunication
station or base station in Power Supply & Environment Surveillance System, FSU
accesses different sensors to get various environment data and non-intelligent
devices status and communicates with intelligent devices (including switching power
supply, Lithium Battery BMS, air-conditioner, etc.) via RS232/485, Modbus or other
kinds of communication interface. FSU captures the following data in real time and
delivers to surveillance center via B-Interface, SNMP protocol.

 Power Supply Parameters
 Voltage and current of 3-phase AC power supply
 Power Rate and Power Factor of AC power supply
 Voltage and current of -48VDC Switching power supply
 Operating Status of Intelligent Switching power supply
 Charging/discharging Voltage and current of backup battery group
 Voltage of Single cell battery
 Surface Temperature of Single Cell battery
 Operating Status of Intelligent Air-Conditioner
 Remote Control of Intelligent Air-Conditioner
 Status and remote control of Diesel Generator
 Embedded over 1000 intelligent devices protocols
 Embedded WEB server
 Environment Status and Control
 Temperature and Humidity - via T&H Sensor
 Smoke status - via Smoke Sensor
 Motion Detection - via Infrared and Microwave Dual Passive Sensor
 Water Logging Status - via Water Sensor
1PM5000 Field Supervision Unit
 Video Snapshot and Storage - via IP camera
 Remote Lighting Control - via Lighting controller
 Remote Entrance Control - via Entrance Guard Controller

2. FSU Dimension

L: 482mm,W: 220mm,H; 44mm

3. FSU Operation Environment

3.1 Environment Temperature
 Operation Temperature: -20℃~60℃
 Storage & Transportation Temperature: -40℃~70℃
3.2 Environment Humidity
 Operation Relative Humidity:<95%
 Storage & Transportation Relative Humidity: <95%(40±2℃)
3.3 Altitude
 <5000m
3.4 Protection Level
 IP20

4.1 Safety Precautions

Please read the following terms carefully before using this product. Improper
installation and usage of this product might cause personal injury and product
damage.

Operators should abide by local laws and regulations, and safety precautions
in this manual should be supplemented only by local safety regulations.
 This product can only be used in indoor or outdoor cabinets. It is forbidden to
use PM5000TT3.0 in inflammable, explosive gas or smoky environment.
 Input power supply voltage should be correct according to this user manual.
 Do not use water to clean any part of the device and wear watches, bracelets,
bracelets, rings and other conductive objects when operating the devices.
 The metal tools used in the installation must be insulated to avoid the short
circuit of the power supply and battery.
 Installation or maintenance operations must comply with the user manual.
 Please measure the voltage of the contact point before contacting the
surface of conductor or connection ports.
 It should be checked routinely according to the user manual after installation
before power on.


7.2 Field Installation Steps

7.2.1 Mount FSU in the cabinet.
7.2.2 Connect cable from target device to the connector terminals of FSU
