Product Details:
Payment & Shipping Terms:
|
| Model: | ET2304000-001 | DC Input Voltage: | -42~-58VDC, Rated: -53.5VDC |
|---|---|---|---|
| AC Output Power: | Single-phase 220Vac | Max. Output Power: | 6kW (2kW×3) |
| Dimensions: | 482.6（W）*350（D）*1U（H） | Installation: | 19-inch Rack-mounted |
| Weight: | ≤8kg (Without Modules) | Cooling Method: | Forced Air Cooling |
Compact -48VDC to 220VAC Inverter DC to AC Power Supply for Telecom Power System 1U Height Power Voltage Converter
1. Introduction of 1U Inverter for Telecom Power System:
The 1U Inverter Chassis features a highly compact design. It supports a maximum AC output current of 45A.
2. Key Features of 1U Inverter for Telecom Power System:
3. Typical Applications of 1U Inverter for Telecom Power System:
4. Technical Parameters of 1U Inverter for Telecom Power System:
| Dimensions | 482.6(W)*350(D)*1U(H) |
| Weight | ≤8kg (Without modules) |
| Cooling Method | Forced air cooling |
| Installation | 19-inch rack-mounted |
| Cable Routing | Front inlet/outlet |
| Maintenance | Front maintenance, supports hot-swapping |
| Protection Level | IP20 |
| AC Output Power | Single-phase 220Vac |
| AC Output Circuit Breaker | 1×32A/2P(1U breaker) |
| AC Outpu Frequency | 45~65Hz, Rated:50Hz/60Hz |
| Max AC Output Power | 6kW(2kW×3) |
| DC Input Voltage | -42~-58VDC, Rated: -53.5VDC |
| DC Input Connector | 300A |
| Input Voltage | -42~-58VDC, Rated: -53.5VDC |
| Efficiency | ≥93% (53.5V input, 220V output) |
| Rated Output Power | 2000W |
| Operating Temperature | -20℃~+75℃(Full load output below 45℃) |
| Dimensions | 106.5mm(W)×286mm(D)×41.5mm(1U/H) |
| Weight | ≤2kg |
| Cooling Method | Forced air cooling |
| Operating Temperature | -20℃~+75℃(Full load output below 45℃) |
| Storage Temperature | -40℃~+75℃ |
| Operating Humidity | 5%~95% |
| Altitude | 0~3000m (At 2000m~3000m, max operating temperature decreases by 1℃ per 200m increase) |
