Payment & Shipping Terms:
|Mounting Method:||Embeded||Input Voltage:||-48VDC|
|Cooling Capacity L35/L35:||2000W||Ingress Protection:||IP55|
outdoor enclosure air conditioner,
control cabinet air conditioner
R134A Refrigerant Outdoor Cabinet Air Conditioner 2000W Energy Saver DC Compressor
1. Key Features
Remote measuring, remote communication, remote control, which can realize multiple automatic protection and comprehensive self-testing function;
Strict process control and international brand parts deployed to ensure high quality and product;
DC Air conditioner, Power supply voltage range;
Fit for harsh condition (T3), R134a refrigerant ;
Low power consumption design with (SEER≥5.5);
LED display, all the settings can changed at the field;
Dry contact alarm output, NO/NC optional;
Anti-theft design, without the protection cover..
|Dimensions (Include flange)||780*482*200mm|
|Application temperature||-40℃ -70 ℃|
|Working temperature||-15℃ -55 ℃|
|Cooling capacity L35/L35||2000 W|
|Power consumption L35/L35||570 W|
|IP grade||IP 55|
3. Installation instructions
In order to avoid short circuit of air duct, it is suggested to make effective isolation between inner air inlet and outlet.
This product is free of cover, customers don’t need to install additional cover.
1. If the customer needs to in-stall a protective cover, in order to ensure enough circulation of air, the opening rate of the air inlet and outlet should be greater than 60%. It is very important to prolong the unit life and reduce the maintenance frequency.
2. The air inlet and outlet of the protective cover should pre-vent short circuit of air duct, so that the air-con can get the best cooling effect.
