Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted

Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted
Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted

Large Image :  Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted

Product Details:
Place of Origin: Shenzhen, China (Mainland)
Brand Name: ESTEL
Certification: ISO9001, CE, 3C, FCC, TLC, IP55
Model Number: ET706085PWF-S
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: wooden case
Delivery Time: 7-15 working days
Payment Terms: T/T, L/C, etc,
Supply Ability: 10,000 sets per month
Detailed Product Description
Cooling: 2 Fans, DC48V, Installed On The Top Protection Leve: IP55
Material: Single Wall, Galvanized Steel, 1.5mm Thickness External Size: W×D×H 700x600x850mm
Installation Method: Wall Mounted, Pole Mounted And Floor Mounted Surface Treatment: Anticrossive Powder Coating
Working Temperature: -20°C ~ 55°C Lock: Anti-theft Three Point Lock
Relative Humidity(RH): 5% ~ 100% Solar Radiation Intensity: 1124 × (1±5%)W/m2
High Light:

wall mounted enclosure

,

outdoor network cabinet





Single Wall Outdoor Cabinet Supporting Three Installation Methods, Wall Mounted, Pole Mounted and Floor Mounted





  • Structure



The cabinet is made of hot dip galvanized steel, single wall structure. It is easy for installation and with perfect sealing performance.


Equipment Compartment: The ET706085PWF-S cabinet is used for installing telecom equipments and battery. The cabinet is a single-wall cabinet, It uses 2 fans for cooling. It is sunproof and waterproof.

Door and Door Lock: The cabinet door uses embedded structure. The door opening angle is larger than 110° and the door limit device can limit the opening angle. The lock is theftproof three point lock, supports padlock.

Cabinet External Size : 700x600x850mm (W×D×H)

Cabinet Internal Size : 610x510x640mm (W×D×H)







  • Dimension Diagram



Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 0Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 1Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 2





  • Applicable Environment Conditions

Working Temperature: -20°C ~ 55°C

Storage Temperature: -40°C ~ + 70°C

Transport Temperature: -50°C ~ +70°C

Relative Humidity(RH): 5% ~ 100%

Air Pressure :62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)

Solar Radiation Intensity: 1124 × (1±5%)W/m2





  • Technical Specs



  • Material: single wall, galvanized steel, 1.5mm thickness
  • Ingress protection: IP55
  • Surface treatment: degreasing, derusting, rustproof phosphating (or galvanizing), powder coated.
  • Equipment Installation Method:19” standard rack and tray
  • With one front door, and anti-theft three point lock for outdoor cabinet (support padlock)
  • Assembled type
  • Cooling : 2 fans, DC48V, installed on the top
  • LED Lamp:DC48V,
  • LED lamp sensor: used for controlling LED lamp on /off

Supporting three installation methods: pole mounted , wall mounted and floor mounted





  • Features



Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 3

Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 4



  • Mounting Method



Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 5



Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 6



Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 7









  • Ventilation



Air Outlet:

Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 8







Air Inlet:



Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 9





  • Packing

The cabinet packing is wooden case in compliance with GB3873-83, damp proof and shock proof. The outside of the packing is painted with damp proof sign, shock proof sign, direction sign, etc.



Single Wall Security Outdoor Electrical Enclosure Supporting Wall Mounted / Pole Mounted and Floor Mounted 10
